Mahindra Maxx Grain 515

Featuress

Best in class acreage per hour
Best in class cleaning efficiency
Multicrop Harvesting capability
Best in Class fuel efficiency

The Mahindra Maxx Grain 515 harvester prioritizes operator comfort with reduced vibrations and minimizes grain loss. Its dual blower speeds enable precise cleaning adjustments, while it boasts exceptional fuel efficiency. With improved ground clearance and maneuverability, maintenance is hassle-free due to interchangeable parts and readily available spares, ensuring reliable performance.

Features

Presence of Straw Walker Technology

For higher performance and minimal losses - Ensures delivery of clean, unbroken grain even in tough conditions. Its design enables harvesting of multiple crops

Presence of Threshing drums

with 600mm diameter and 1274 mm width is capable of handling heavy crop flows with best performance, the availability of mechanical variator, gives speed range from 525 - 1125 rpm. Speed range makes the machine to work in different field conditions

14 feet Cutter-bar: 2.6 m (8.5 ft.) with single knife for excellent operations under difficult fields. Hexagonal reel and huge trough for outstanding material intake.

Engine power supply

Fuel Efficient Mahindra Engine with 73.5 kw @2200rpm ( emission class BSIV)

Huge Grain Tank with Cover

Higher volume of 2500 liters guarantees longer operational time. Weather independent. easy maintenance and visibility. Thanks to window near operator's seat to have a view of filling levels of grain in tank during operations

Canopy

High quality, large-sized roof ensures maximum comfort for the operator. Longer shelf life due to presence of good quality fiber material.

Higher Ground Clearance of 435 mm helps the machine to cross the large bunds

High maneuverability

Fitted with 18.4/15-30 14PR tyres at the front and 9.0- 16/ 16 PR on the rear for easy to maneuver in fields

Parameters	Technical Specifications	Technical Specification
Engine	Model	MCVNC35TI110CE4
Engine	Power	73.5 kW @ 2200 rpm
Engine	Air Cleaner	Dry Type, heavy duty
Engine	Engine Type	Direct injection, four stroke, Charger intercool diesel engine
Engine	Rated engine speed (rpm)	2200+50
Engine	Max engine output (KW @rpm) (declared value)	74.8@2250
Engine	Rated engine out put (KW @ rpm) (declared value)	735 @ 2200
Cutting Mechanism	Cutter bar width	4.2m(14 ft)
Cutting Mechanism	Minimum Cutting Height (mm)	60
Reel	Speed Control	Using Mechanical Variator
Reel	Height Control	Using Hydraulic system
Threshing and Cleaning	Threshing Drum width (mm)	1274
Threshing and Cleaning	Diameter (mm)	600
Threshing and Cleaning	Speed Control/ Speed Range(RPM)	525-1125
Threshing and Cleaning	Adjustment	Mechanical
Concave	Clearance	Adjustable mechanical
Straw Walker	Number	5
Straw Walker	Number of Steps	6
Straw Walker	Area	4.8 sq meter
Cleaning Area	Upper Sieve (m2)	2.21 Sq. meter
Cleaning Area	Lower Sieve	1.5 Sq. meter
Cleaning Area	Adjustment	Mechanical
Tyres	Front	(18.4/15-30) 14 PR
Tyres	Rear	(9-16) 16 PR
Speed on Road	Forward
Speed on Road	First Gear	9710415 Km
Speed on Road	Second Gear	44510 9.37 km
Speed on Road	Third gear	11.04 to 23.25 km
Speed on Road	Reverse	4.93 to 10.38 km
Wheel Track	mm	2480mm
Wheel base	mm	3600 mm
Steering and Brake	Steering	Hydraulic
Steering and Brake	Brake	Disc type mechanical
Efficiency	Grain tank capacity	2500 L
Efficiency	Diesel Tank	245 L

Main Dimensions	During transport	During harvest
Width	3160 mm	6160 mm
Length	12210mm	8940 mm
Height	3960 mm	3960 mm
Ground clearance	385 mm

Weight	Value
Machine (without cutter bar)	7400 kg
Cutter bar and trailer (together)	1460 kg
